Тормозные гидравлические клапаны Walvoil:

Тормозные гидравлические клапаны Walvoil

Теги : Клапан тормозной Walvoil   Overcenter valves Walvoil Counterbalance valves Односторонний тормозной клапан  Клапан тормозной односторонний с предохранительным  Клапан тормозной односторонний фланцевого монтажа  Клапан тормозной односторонний для гидромотора Двусторонний тормозной клапан с предохранительным клапаном  Двусторонний тормозной клапан с частичной компенсацией   Двусторонний тормозной клапан с полной  компенсацией  Клапан тормозной двусторонний фланцевого монтажа   Двусторонний тормозной клапан с регенерацией потока Регенеративный тормозной клапан Клапан давления с гидроуправлением от гидравлического джойстика Тормозной клапан с встроенным клапаном сброса  Тормозной клапан с встроенным клапаном “by-pass” Клапан давления



Type VOSL/N78/.... Односторонний тормозной клапан Single acting Load sensitive

40 l/min (10.57 US gpm)

Max. pressure Steel body = 350 bar (5100 psi)

Oil leakage 0.25 cm3/min - 0.015 in3/min. (5 drops) at 80% of pressure setting

Fluid mineral based oil

Viscosity from 10 to 200 cSt

Max. level of contamination 18/16/13 ISO4406

Fluid temperature with NBR seals from -20°C (-4°F) to 80°C (176°F)

Environmental temp. for working conditions from -40°C (-40°F) to 100°C (212°F)

steel 0.723 kg ( 1.59 lb)

VOSL/N78 complete valves

TYPE: VOSL/N78/14/G5.p4/ac CODE: 1513512100

DESCRIPTION: Steel body, pilot ratio 1:4, range 100-350 bar (1450-

5075 psi), standard setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N78/14/G3.p4/ac CODE: 1513512101

DESCRIPTION: Steel body, pilot ratio 1:4, range 60-220 bar (870-

3190 psi), standard setting 150 bar (2170 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N78/S6/G5.p4/ac CODE: 1513512200

DESCRIPTION: Steel body, pilot ratio 1:4, range 100-350 bar (1450-

5075 psi), standard setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N78/S6/G3.p4/ac CODE: 1513512201

DESCRIPTION: Steel body, pilot ratio 1:4, range 60-220 bar (870-

3190 psi), standard setting 150 bar (2170 psi) @ 5 l/min (1.32 US gpm)

VOSL/N78....PB complete valves

TYPE: VOSL/N78/14PB/G5.p4/ac CODE: 1513612100

DESCRIPTION: Steel body, pilot ratio 1:4, range 100-350 bar (1450-

5075 psi), standard setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N78/14PB/G3.p4/ac CODE: 1513612101

DESCRIPTION: Steel body, pilot ratio 1:4, range 60-220 bar (870-

3190 psi), standard setting 150 bar (2170 psi) @ 5 l/min (1.32 US gpm)





Type VOSLP/N78/.... Односторонний тормозной клапан Single acting External pilot

VOSLP/N78 - VOSLP/N78/..PB

Nominal flow 40 l/min (10.57 US gpm)

Max. pressure Steel body = 350 bar (5100 psi)

Oil leakage 0.25 cm3/min - 0.015 in3/min. (5 drops) at 80% of pressure setting

Fluid mineral based oil

Viscosity from 10 to 200 cSt

Max. level of contamination 18/16/13 ISO4406

Fluid temperature with NBR seals from -20°C (-4°F) to 80°C (176°F)

Environmental temp. for working conditions from -40°C (-40°F) to 100°C (212°F)

steel 0.723 kg ( 1.59 lb)

VOSLP/N78 complete valves

TYPE: VOSLP/N78/14/G5.p4/ac CODE: 1533612100

DESCRIPTION: Steel body, pilot ratio 1:4, range 100-350 bar (1450-

5075 psi), standard setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N78/14/G3.p4/ac CODE: 1533612101

DESCRIPTION: Steel body, pilot ratio 1:4, range 60-220 bar (870-

3190 psi), standard setting 150 bar (2170 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N78/S6/G5.p4/ac CODE: 1533612200

DESCRIPTION: Steel body, pilot ratio 1:4, range 100-350 bar (1450-

5075 psi), standard setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N78/S6/G3.p4/ac CODE: 1533612201

DESCRIPTION: Steel body, pilot ratio 1:4, range 60-220 bar (870-

3190 psi), standard setting 150 bar (2170 psi) @ 5 l/min (1.32 US gpm)



Type VOSLP/N78/  Двусторонний тормозной клапан   Double acting  Load sensitive

VODL/N78 - VODL/N78/..PB

Nominal flow 40 l/min (10.57 US gpm)

Max. pressure Steel body = 350 bar (5100 psi)

Oil leakage 0.25 cm3/min - 0.015 in3/min. (5 drops) at 80% of pressure setting

Fluid mineral based oil

Viscosity from 10 to 200 cSt

Max. level of contamination 18/16/13 ISO4406

Fluid temperature with NBR seals from -20°C (-4°F) to 80°C (176°F)

Environmental temp. for working conditions from -40°C (-40°F) to 100°C (212°F)

steel 1.25 kg ( 2.75 lb)

VODL/N78 complete valves

TYPE: VODL/N78/14/G5.p4/ac CODE: 1553612100

DESCRIPTION: Steel body, pilot ratio 1:4, range 100-350 bar (1450-

5075 psi), standard setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N78/14/G3.p4/ac CODE: 1553612101

DESCRIPTION: Steel body, pilot ratio 1:4, range 60-220 bar (870-

3190 psi), standard setting 150 bar (2170 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N78/S6/G5.p4/ac CODE: 1553612200

DESCRIPTION: Steel body, pilot ratio 1:4, range 100-350 bar (1450-

5075 psi), standard setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N78/S6/G3.p4/ac CODE: 1553612201

DESCRIPTION: Steel body, pilot ratio 1:4, range 60-220 bar (870-

3190 psi), standard setting 150 bar (2170 psi) @ 5 l/min (1.32 US gpm)

VODL/N78....PB complete valves

TYPE: VODL/N78/14PB/G5.p4/ac CODE: 1553712100

DESCRIPTION: Steel body, pilot ratio 1:4, range 100-350 bar (1450-

5075 psi), standard setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N78/14PB/G3.p4/ac CODE: 1553712101

DESCRIPTION: Steel body, pilot ratio 1:4, range 60-220 bar (870-

3190 psi), standard setting 150 bar (2170 psi) @ 5 l/min (1.32 US gpm)



Type VOSL/N1116 - VOSL/R1116 - VOSL/V1116  Односторонний тормозной клапан

Single acting • Load Sensitive (type N) • Relief compensated (type R) • Vented (type V) • Configuration with F1 and F2 flange



VOSL/N1116 (38-12) - VOSL/R1116 (38-12) - VOSL/V1116 (38-12)

Nominal flow 60 l/min (15.9 US gpm)

Max. pressure

Aluminium body = 210 bar (3050 psi)

Steel body = 350 bar (5100 psi)

Oil leakage 0.25 cm3/min - 0.015 in3/min. (5 drops) at 210 bar - 3050 psi

Fluid mineral based oil

Viscosity from 10 to 200 cSt

Max. level of contamination 18/16/13 ISO4406

Fluid temperature with NBR seals from -20°C (-4°F) to 80°C (176°F)

Environmental temp. for working conditions from -40°C (-40°F) to 100°C (212°F)

Weight

aluminium

VOSL/N1116/38: 0.59 kg (1.30 lb) - VOSL/N1116/12: 0.75 kg (1.65 lb)

VOSL/R1116/38: 0.64 kg (1.41 lb) - VOSL/R1116/12: 0.82 kg (1.81 lb)

VOSL/V1116/38: 0.66 kg (1.46 lb) - VOSL/V1116/12: 0.83 kg (1.83 lb)

steel

VOSL/N1116/38: 1.31 kg (2.88 lb) - VOSL/N1116/12: 1.74 kg (3.84 lb)

VOSL/N1116/38PB: - VOSL/N1116/12PB:

VOSL/R1116/38: 1.34 kg (2.95 lb) - VOSL/R1116/12: 1.73 kg (3.81 lb)

VOSL/V1116/38: 1.36 kg (2.88 lb) - VOSL/V1116/12: 1.78 kg (3.92 lb)



VOSL/N1116 complete valves

Load sensitive (N) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VOSL/N1116/38/G3.p4/ac CODE: 1514322101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/38/G5.p4/ac CODE: 1514322100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/38/G5.p4 CODE: 1514321100

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/N1116/38/G5.p8/ac CODE:1514322104

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/N1116/38/G3.p0/ac CODE: 1514322106

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi). Std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/38/G5.p0/ac CODE: 1514322107

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G3/8 thread and F1 flange

TYPE: VOSL/N1116/38F1/G5.p4/ac CODE: 1515022100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/38F1/G5.p8/ac CODE: 1515022101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075

psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/38F1/G5.p0/ac CODE: 1515022102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G3/8 thread and F2 flange

TYPE: VOSL/N1116/38F2/G5.p4/ac CODE: 1515022103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/38F2/G5.p8/ac CODE: 1515022104

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/38F2/G5.p0/ac CODE: 1515022105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



VOSL/N1116 complete valves (continua)

Load sensitive (N) configuration with SAE8 thread

Pilot ratio 1:4

TYPE: VOSL/N1116/S8/G3.p4/ac CODE: 1514322200

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S8/G5.p4/ac CODE: 1514322201

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S8/G5.p4 CODE: 1514321200

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/N1116/S8/G5.p8/ac CODE:1514322204

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/N1116/S8/G3.p0/ac CODE: 1514322206

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi). Std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S8/G5.p0/ac CODE: 1514322207

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE8 thread and F1 flange

TYPE: VOSL/N1116/S8F1/G5.p4/ac CODE: 1515022200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S8F1/G5.p8/ac CODE: 1515022201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075

psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S8F1/G5.p0/ac CODE: 1515022202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE8 thread and F2 flange

TYPE: VOSL/N1116/S8F2/G5.p4/ac CODE: 1515022203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S8F2/G5.p8/ac CODE: 1515022204

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S8F2/G5.p0/ac CODE: 1515022205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



VOSL/N1116 complete valves

Load sensitive (N) configuration with G1/2 thread

TYPE: VOSL/N1116/12/G5.p4/ac CODE: 1514332100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/12/G5.p8/ac CODE: 1514332101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/12/G5.p0/ac CODE: 1514332102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/12/G5.p4 CODE: 1514331100

DESCRIPTION: Aluminium body, pilot ratio 1:4 range 50-350 bar (725-

5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G1/2 thread and F1 flange

TYPE: VOSL/N1116/12F1/G5.p4/ac CODE: 1515032100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/12F1/G5.p8/ac CODE: 1515032101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/12F1/G5.p0/ac CODE: 1515032102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G1/2 thread and F1 flange

TYPE: VOSL/N1116/12F2/G5.p4/ac CODE: 1515032103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/12F2/G5.p8/ac CODE: 1515032104

DESCRIPTION: Steel body, pilot ratio 1:8. Range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/12F2/G5.p0/ac CODE: 1515032105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.



VOSL/N1116 complete valves

Load sensitive (N) configuration with SAE10 thread

TYPE: VOSL/N1116/S10/G5.p4/ac CODE: 1514332200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S10/G5.p8/ac CODE: 1514332201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S10/G5.p0/ac CODE: 1514332202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE10 thread and F1

flange

TYPE: VOSL/N1116/S10F1/G5.p4/ac CODE: 1515032200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S10F1/G5.p8/ac CODE: 1515032201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S10F1/G5.p0/ac CODE: 1515032202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE10 thread and F2

flange

TYPE: VOSL/N1116/S10F2/G5.p4/ac CODE: 1515032203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S10F2/G5.p8/ac CODE: 1515032204

DESCRIPTION: Steel body, pilot ratio 1:8. Range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/S10F2/G5.p0/ac CODE: 1515032205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.

1 Pressure setting spring

TYPE CODE DESCRIPTION

For 1:4 and zero differential pilot ratio

3 3ML1133201 For range 5-210 bar (72.5-3050 psi)

5 3ML1133200 For range 50-350 bar (725-5075 psi)

For 1:8 pilot ratio

5 3ML1133201 For range 5-350 bar (72.5-5075 psi)

2 Setting type

TYPE CODE DESCRIPTION

G - Screw setting

Z 4COP120420 Antitampering cap





VOSL/R1116 complete valves

Relief compensated (R) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VOSL/R1116/38/G3.p4/ac CODE: 1514422101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/38/G5.p4/ac CODE: 1514422100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/38/G5.p4 CODE: 1514421100

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/R1116/38/G5.p8/ac CODE: 1514422104

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/R1116/38/G3.p0/ac CODE: 1514422106

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/38/G5.p0/ac CODE: 1514422107

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G3/8 thread and F1 flange

TYPE: VOSL/R1116/38F1/G5.p4/ac CODE: 1515122100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075

psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/38F1/G5.p8/ac CODE: 1515122101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/38F1/G5.p0/ac CODE: 1515122102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G3/8 thread and F2 flange

TYPE: VOSL/R1116/38F2/G5.p4/ac CODE: 1515122103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/38F2/G5.p8/ac CODE: 1515122104

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/38F2/G5.p0/ac CODE: 1515122105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)





VOSL/R1116 complete valves

Relief compensated (R) configuration with SAE8 thread

Pilot ratio 1:4

TYPE: VOSL/R1116/S8/G3.p4/ac CODE: 1514422200

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S8/G5.p4/ac CODE: 1514422201

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/R1116/S8/G5.p8/ac CODE: 1514422204

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/R1116/S8/G3.p0/ac CODE: 1514422206

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S8/G5.p0/ac CODE: 1514422207

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with SAE8 thread and F1 flange

TYPE: VOSL/R1116/S8F1/G5.p4/ac CODE: 1515122200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075

psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S8F1/G5.p8/ac CODE: 1515122201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S8F1/G5.p0/ac CODE: 1515122202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with SAE8 thread and F2 flange

TYPE: VOSL/R1116/S8F2/G5.p4/ac CODE: 1515122203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S8F2/G5.p8/ac CODE: 1515122204

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S8F2/G5.p0/ac CODE: 1515122205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)\



VOSL/R1116 complete valves

Relief compensated (R) configuration with G1/2 thread

TYPE: VOSL/R1116/12/G5.p4/ac CODE: 1514432100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/12/G5.p8/ac CODE: 1514432101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/12/G5.p0/ac CODE: 1514432102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/12/G5.p4 CODE: 1514431100

DESCRIPTION: Aluminium body, pilot ratio 1:4, range 50-350 bar (725-

5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G1/2 thread and F1

flange

TYPE: VOSL/R1116/12F1/G5.p4/ac CODE: 1515132100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/12F1/G5.p8/ac CODE: 1515132101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

stdsetting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/12F1/G5.p0/ac CODE: 1515132102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G1/2 thread and F2

flange

TYPE: VOSL/R1116/12F2/G5.p4/ac CODE: 1515132103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/12F2/G5.p8/ac CODE: 1515132104

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/12F2/G5.p0/ac CODE: 1515132105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.



VOSL/R1116 complete valves

Relief compensated (R) configuration with SAE10 thread

TYPE: VOSL/R1116/S10/G5.p4/ac CODE: 1514432200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S10/G5.p8/ac CODE: 1514432201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S10/G5.p0/ac CODE: 1514432202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S10/G5.p4 CODE: 1514431200

DESCRIPTION: Aluminium body, pilot ratio 1:4, range 50-350 bar (725-

5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with SAE10 thread and

F1 flange

TYPE: VOSL/R1116/S10F1/G5.p4/ac CODE: 1515132200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S10F1/G5.p8/ac CODE: 1515132201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

stdsetting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/R1116/S10F1/G5.p0/ac CODE: 1515132202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with



VOSL/V1116 complete valves

Vented (V) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VOSL/V1116/38/G3.p4/ac CODE: 1514522101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/38/G5.p4/ac CODE: 1514522100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/38/G5.p4 CODE: 1514521100

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/V1116/38/G5.p8/ac CODE: 1514522104

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/V1116/38/G3.p0/ac CODE: 1514522106

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/38/G5.p0/ac CODE: 1514522107

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G3/8 thread and F1 flange

TYPE: VOSL/V1116/38F1/G5.p4/ac CODE: 1515222100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/38F1/G5.p8/ac CODE: 1515222101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE:VOSL/V1116/38F1/G5.p0/ac CODE: 1515222102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G3/8 thread and F2 flange

TYPE: VOSL/V1116/38F2/G5.p4/ac CODE: 1515222103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/38F2/G5.p8/ac CODE: 1515222104

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/38F2/G5.p0/ac CODE: 1515222105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



VOSL/V1116 complete valves

Vented (V) configuration with SAE8 thread

Pilot ratio 1:4

TYPE: VOSL/V1116/S8/G3.p4/ac CODE: 1514522200

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S8/G5.p4/ac CODE: 1514522201

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/V1116/S8/G5.p8/ac CODE: 1514522204

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/V1116/S8/G3.p0/ac CODE: 1514522206

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S8/G5.p0/ac CODE: 1514522207

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with SAE8 thread and F1 flange

TYPE: VOSL/V1116/S8F1/G5.p4/ac CODE: 1515222200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S8F1/G5.p8/ac CODE: 1515222201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE:VOSL/V1116/S8F1/G5.p0/ac CODE: 1515222202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with SAE8 thread and F2 flange

TYPE: VOSL/V1116/S8F2/G5.p4/ac CODE: 1515222203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S8F2/G5.p8/ac CODE: 1515222204

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S8F2/G5.p0/ac CODE: 1515222205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



VOSL/V1116 complete valves

Vented (V) configuration with G1/2 thread

TYPE: VOSL/V1116/12/G5.p4/ac CODE: 1514532100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/12/G5.p8/ac CODE: 1514532101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/12/G5.p0/ac CODE: 1514532102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/12/G5.p4 CODE: 1514531100

DESCRIPTION: Aluminium body pilot ratio 1:4, range 50-350 bar (725-

5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

Vented (V) configuration with G1/2 thread and F1 flange

TYPE: VOSL/V1116/12F1/G5.p4/ac CODE: 1515232100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/12F1/G5.p8/ac CODE: 1515232101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/12F1/G5.p0/ac CODE: 1515232102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G1/2 thread and F2 flange

TYPE: VOSL/V1116/12F2/G5.p4/ac CODE: 1515232103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/12F2/G5.p8/ac CODE: 1515232104

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/12F2/G5.p0/ac CODE: 1515232105

DESCRIPTION: Steel body, zero differential pilot ratio,



VOSL/V1116 complete valves

Vented (V) configuration with SAE10 thread

TYPE: VOSL/V1116/S10/G5.p4/ac CODE: 1514532200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S10/G5.p8/ac CODE: 1514532201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S10/G5.p0/ac CODE: 1514532202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with SAE10 thread and F1 flange

TYPE: VOSL/V1116/S10F1/G5.p4/ac CODE: 1515232200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S10F1/G5.p8/ac CODE: 1515232201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S10F1/G5.p0/ac CODE: 1515232202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with SAE10 thread and F2 flange

TYPE: VOSL/V1116/S10F2/G5.p4/ac CODE: 1515232203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S10F2/G5.p8/ac CODE: 1515232204

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1116/S10F2/G5.p0/ac CODE: 1515232205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.





VOSL/N1116/PB complete valves

Load sensitive (N) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VOSL/N1116/38PB/G3.p4/ac CODE: 1554222101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/38PB/G5.p4/ac CODE: 1514222100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/N1116/38PB/G5.p8/ac CODE:1514222102

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/N1116/38PB/G5.p0/ac CODE: 1514222103

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G1/2 thread

Pilot ratio 1:4

TYPE: VOSL/N1116/12PB/G3.p4/ac CODE: 1514232101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1116/12PB/G5.p4/ac CODE: 1514232100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/N1116/12PB/G5.p8/ac CODE:1514232102

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/N1116/12PB/G5.p0/ac CODE: 1514232103

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.







Type VOSLP/N1116 - VOSLP/R1116 Односторонний тормозной клапан counterbalance valves • Single acting • External pilot • Load Sensitive (type N) • Relief Compensated (type R

VOSLP/N1116 (38-12) - VOSLP/R1116 (38-12)

Nominal flow 60 l/min (15.9 US gpm)

Max. pressure

Aluminium body = 210 bar (3050 psi)

Steel body = 350 bar (5100 psi)

Oil leakage 0.25 cm3/min - 0.015 in3/min. (5 drops) at 210 bar - 3050 psi

Fluid mineral based oil

Viscosity from 10 to 200 cSt

Max. level of contamination 18/16/13 ISO4406

Fluid temperature with NBR seals from -20°C (-4°F) to 80°C (176°F)

Environmental temp. for working conditions from -40°C (-40°F) to 100°C (212°F)

Weight

aluminium VOSLP/N1116/38: 0.51kg (1.12 lb) - VOSLP/N1116/12: 0.65 kg (1.43 lb)

steel

VOSLP/N1116/38: 1.13 kg (2.49 lb) - VOSLP/N1116/12: 1.51 kg (3.33 lb)

VOSLP/R1116/38: 1.20 kg (2.64 lb) - VOSLP/R1116/12: 1.58 kg (3.48 lb)



VOSLP/N1116 complete valves

Load sensitive (N) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VOSLP/N1116/38/G3.p4/ac CODE: 1534322101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/38/G5.p4/ac CODE: 1534322100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi). std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/38/G5.p4 CODE: 1534321100

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSLP/N1116/38/G5.p8/ac CODE: 1534322104

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSLP/N1116/38/G3.p0/ac CODE: 1534322106

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/38/G5.p0/ac CODE: 1534322107

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G3/8 thread and F1 flange

TYPE: VOSLP/N1116/38F1/G5.p4/ac CODE: 1535522100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/38F1/G5.p8/ac CODE: 1535522101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/38F1/G5.p0/ac CODE: 1535522102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



VOSLP/N1116 complete valves

Load sensitive (N) configuration with SAE8 thread

Pilot ratio 1:4

TYPE: VOSLP/N1116/S8/G3.p4/ac CODE: 1534322200

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S8/G5.p4/ac CODE: 1534322201

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi). std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S8/G5.p4 CODE: 1534321200

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSLP/N1116/S8/G5.p8/ac CODE: 1534322204

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSLP/N1116/S8/G3.p0/ac CODE: 1534322206

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S8/G5.p0/ac CODE: 1534322207

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE8 thread and F1 flange

TYPE: VOSLP/N1116/S8F1/G5.p4/ac CODE: 1535522200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S8F1/G5.p8/ac CODE: 1535522201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S8F1/G5.p0/ac CODE: 1535222202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



VOSLP/N1116 complete valves

Load sensitive (N) configuration with G1/2 thread

TYPE: VOSLP/N1116/12/G5.p4/ac CODE: 1534332100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/12/G5.p8/ac CODE: 1534332101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/12/G5.p0/ac CODE: 1534332102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/12/G5.p4 CODE: 1534331100

DESCRIPTION: Aluminium body, pilot ratio 1:4, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G1/2 thread and F1 flange

TYPE: VOSLP/N1116/12F1/G5.p4/ac CODE: 1535532100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/12F1/G5.p8/ac CODE: 1535532101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/12F1/G5.p0/ac CODE: 1535532102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.



VOSLP/N1116 complete valves

Load sensitive (N) configuration with SAE10 thread

TYPE: VOSLP/N1116/S10/G5.p4/ac CODE: 1534332200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S10/G5.p8/ac CODE: 1534332201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S10/G5.p0/ac CODE: 1534332202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S10/G5.p4 CODE: 1534331200

DESCRIPTION: Aluminium body, pilot ratio 1:4, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE10 thread and F1

flange

TYPE: VOSLP/N1116/S10F1/G5.p4/ac CODE: 1535532200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S10F1/G5.p8/ac CODE: 1535532201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/N1116/S10F1/G5.p0/ac CODE: 1535532202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.



VOSLP/R1116 complete valves

Relief compensated (R) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VOSLP/R1116/38/G3.p4/ac CODE: 1534422101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/38/G5.p4/ac CODE: 1534422100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSLP/R1116/38/G5.p8/ac CODE: 1534422104

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSLP/R1116/38/G3.p0/ac CODE: 1534422106

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/38/G5.p0/ac CODE: 1534422107

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G3/8 thread and F1 flange

TYPE: VOSLP/R1116/38F1/G5.p4/ac CODE: 1535622100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/38F1/G5.p8/ac CODE: 1535622101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/38F1/G5.p0/ac CODE: 1535622102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



VOSLP/R1116 complete valves

Relief compensated (R) configuration with SAE8 thread

Pilot ratio 1:4

TYPE: VOSLP/R1116/S8/G3.p4/ac CODE: 1534422200

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/S8/G5.p4/ac CODE: 1534422201

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSLP/R1116/S8/G5.p8/ac CODE: 1534422204

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSLP/R1116/S8/G3.p0/ac CODE: 1534422206

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/S8/G5.p0/ac CODE: 1534422207

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with SAE8 thread and F1 flange

TYPE: VOSLP/R1116/S8F1/G5.p4/ac CODE: 1535622200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/S8F1/G5.p8/ac CODE: 1535622201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/S8F1/G5.p0/ac CODE: 1535522202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



VOSLP/R1116 complete valves

Relief compensated (R) configuration with G1/2 thread

TYPE: VOSLP/R1116/12/G5.p4/ac CODE: 1534432100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/12/G5.p8/ac CODE: 1534432101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/12/G5.p0/ac CODE: 1534432102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G1/2 thread and F1 flange

TYPE: VOSLP/R1116/12F1/G5.p4/ac CODE: 1535632100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/12F1/G5.p8/ac CODE: 1535632101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/12F1/G5.p0/ac CODE: 1535632102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.





VOSLP/R1116 complete valves

Relief compensated (R) configuration with SAE10 thread

TYPE: VOSLP/R1116/S10/G5.p4/ac CODE: 1534432200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/S10/G5.p8/ac CODE: 1534432201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/S10/G5.p0/ac CODE: 1534432202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with SAE10 thread and F1

flange

TYPE: VOSLP/R1116/S10F1/G5.p4/ac CODE: 1535632200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/S10F1/G5.p8/ac CODE: 1535632201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSLP/R1116/S10F1/G5.p0/ac CODE: 1535632202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.



Type VODL/N1116 - VODL/R1116 Двусторонний тормозной клапан   Double acting counterbalance valves  • Double acting • Load Sensitive (type N) • Relief Compensated (type R)

VODL/N1116 (38-12) - VODL/R1116 (38-12)

Nominal flow 60 l/min (15.9 US gpm)

Max. pressure

Aluminium body = 210 bar (3050 psi)

Steel body = 350 bar (5100 psi)

Oil leakage 0.25 cm3/min - 0.015 in3/min. (5 drops) at 210 bar - 3050 psi

Fluid mineral based oil

Viscosity from 10 to 200 cSt

Max. level of contamination 18/16/13 ISO4406

Fluid temperature with NBR seals from -20°C (-4°F) to 80°C (176°F)

Environmental temp. for working conditions from -40°C (-40°F) to 100°C (212°F)

Weight

aluminium

VODL/N1116/38: 0.91 kg (2.01 lb) - VODL/N1116/12: 1.13 kg (2.49 lb)

VODL/R1116/38: 1.06 kg (2.34 lb) - VODL/R1116/12: 1.29 kg (2.84 lb)

steel

VODL/N1116/38: 1.91 kg (4.21 lb) - VODL/N1116/12: 2.55 kg (5.62 lb)

VODL/N1116/38PB: - VODL/N1116/12PB:

VODL/R1116/38: 2.06 kg (4.54 lb) - VODL/R1116/12: 2.69 kg (5.93 lb)

NOTE - For different conditions, please contact Walvoil Sales Dpt.





VODL/N1116 complete valves

Load sensitive (N) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VODL/N1116/38/G3.p4/ac CODE: 1554322103

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/38/G5.p4/ac CODE: 1554322100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/38/G5.p4 CODE: 1554321100

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VODL/N1116/38/G5.p8/ac CODE: 1554322106

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VODL/N1116/38/G3.p0/ac CODE: 1554322108

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/38/G5.p0/ac CODE: 1554322109

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G3/8 thread and F1 flange

TYPE: VODL/N1116/38F1/G5.p4/ac CODE: 1555122100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/38F1/G5.p8/ac CODE: 1555122101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/38F1/G5.p0/ac CODE: 1555122102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G3/8 thread and F2 flange

TYPE: VODL/N1116/38F2/G5.p4/ac CODE: 1555122103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/38F2/G5.p8/ac CODE: 1555122104

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/38F2/G5.p0/ac CODE: 1555122105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)





VODL/N1116 complete valves

Load sensitive (N) configuration with SAE8 thread

Pilot ratio 1:4

TYPE: VODL/N1116/S8/G3.p4/ac CODE: 1554322200

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S8/G5.p4/ac CODE: 1554322201

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S8/G5.p4 CODE: 1554321200

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VODL/N1116/S8/G5.p8/ac CODE: 1554322204

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VODL/N1116/S8/G3.p0/ac CODE: 1554322206

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S8/G5.p0/ac CODE: 1554322207

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE8 thread and F1 flange

TYPE: VODL/N1116/S8F1/G5.p4/ac CODE: 1555122200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S8F1/G5.p8/ac CODE: 1555122201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S8F1/G5.p0/ac CODE: 1555122202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE8 thread and F2 flange

TYPE: VODL/N1116/S8F2/G5.p4/ac CODE: 1555122203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S8F2/G5.p8/ac CODE: 1555122204

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S8F2/G5.p0/ac CODE: 1555122205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)





VODL/N1116 complete valves

Load sensitive (N) configuration with G1/2 thread

TYPE: VODL/N1116/12/G5.p4/ac CODE: 1554332100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075

psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/12/G5.p8/ac CODE: 1554332101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075

psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/12/G5.p0/ac CODE: 1554332102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/12/G5.p4 CODE: 1554331100

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G1/2 thread and F1 flange

TYPE: VODL/N1116/12F1/G5.p4/ac CODE: 1555132100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/12F1/G5.p8/ac CODE: 1555132101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/12F1/G5.p0/ac CODE: 1555132102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G1/2 thread and F2 flange

TYPE: VODL/N1116/12F2/G5.p4/ac CODE: 1555132103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/12F2/G5.p8/ac CODE: 1555132104

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/12F2/G5.p0/ac CODE: 1555132105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.





VODL/N1116 complete valves

Load sensitive (N) configuration with SAE10 thread

TYPE: VODL/N1116/S10/G5.p4/ac CODE: 1554332200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075

psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S10/G5.p8/ac CODE: 1554332201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075

psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S10/G5.p0/ac CODE: 1554332202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S10/G5.p4 CODE: 1554331201

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE10 thread and F1

flange

TYPE: VODL/N1116/S10F1/G5.p4/ac CODE: 1555132200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S10F1/G5.p8/ac CODE: 1555132201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S10F1/G5.p0/ac CODE: 1555132202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE10 thread and F2

flange

TYPE: VODL/N1116/S10F2/G5.p4/ac CODE: 1555132203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S10F2/G5.p8/ac CODE: 1555132204

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/S10F2/G5.p0/ac CODE: 1555132205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.



VODL/R1116 complete valves

Relief compensated (R) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VODL/R1116/38/G3.p4/ac CODE: 1554422101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/38/G5.p4/ac CODE: 1554422100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/38/G5.p4 CODE: 1554421100

DESCRIPTION: aluminium body configuration range 50-350 bar (725-

5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VODL/R1116/38/G5.p8/ac CODE: 1554422104

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VODL/R1116/38/G3.p0/ac CODE: 1554422106

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/38/G5.p0/ac CODE: 1554422107

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G3/8 thread and F1

flange

TYPE: VODL/R1116/38F1/G5.p4/ac CODE: 1555022100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/38F1/G5.p8/ac CODE: 1555022101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/38F1/G5.p0/ac CODE: 1555022102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G3/8 thread and F2

flange

TYPE: VODL/R1116/38F2/G5.p4/ac CODE: 1555022103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4 060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/38F2/G5.p8/ac CODE: 1555022104

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/38F2/G5.p0/ac CODE: 1555022105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350

bar (725-5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)





VODL/R1116 complete valves

Relief compensated (R) configuration with SAE8 thread

Pilot ratio 1:4

TYPE: VODL/R1116/S8/G3.p4/ac CODE: 1554422200

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S8/G5.p4/ac CODE: 1554422201

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S8/G5.p4 CODE: 1554421200

DESCRIPTION: aluminium body configuration range 50-350 bar (725-

5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VODL/R1116/S8/G5.p8/ac CODE: 1554422204

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VODL/R1116/S8/G3.p0/ac CODE: 1554422206

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S8/G5.p0/ac CODE: 1554422207

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with SAE8 thread and F1

flange

TYPE: VODL/R1116/S8F1/G5.p4/ac CODE: 1555022200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S8F1/G5.p8/ac CODE: 1555022201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S8F1/G5.p0/ac CODE: 1555022202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with SAE8 thread and F2

flange

TYPE: VODL/R1116/S8F2/G5.p4/ac CODE: 1555022203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4 060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S8F2/G5.p8/ac CODE: 1555022204

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S8F2/G5.p0/ac CODE: 1555022205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350

bar (725-5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm





VODL/R1116 complete valves

Relief compensated (R) configuration with G1/2 thread

TYPE: VODL/R1116/12/G5.p4/ac CODE: 1554432101

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/12/G5.p8/ac CODE: 1554432100

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/12/G5.p0/ac CODE: 1554432102

DESCRIPTION: Steel body, zero differential pilot ratio. Range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/12/G5.p4 CODE: 1554431100

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G1/2 thread and F1

flange

TYPE: VODL/R1116/12F1/G5.p4/ac CODE: 1555032103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075

psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/12F1/G5.p8/ac CODE: 1555032104

DESCRIPTION: pilot ratio 1:8, range 5-350 bar (72.5-5075 psi), std

setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/12F1/G5.p0/ac CODE: 1555032105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350

bar (725-5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with G1/2 thread and F2

flange

TYPE: VODL/R1116/12F2/G5.p4/ac CODE: 1555032100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075

psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/12F2/G5.p8/ac CODE: 1555032101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075

psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/12F2/G5.p0/ac CODE: 1555032102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350

bar (725-5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.



VODL/R1116 complete valves

Relief compensated (R) configuration with SAE10 thread

TYPE: VODL/R1116/S10/G5.p4/ac CODE: 1554432200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S10/G5.p8/ac CODE: 1554432201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S10/G5.p0/ac CODE: 1554432202

DESCRIPTION: Steel body, zero differential pilot ratio. Range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S10/G5.p4 CODE: 1554431200

DESCRIPTION: Aluminium body, range 50-350 bar (725-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with SAE10 thread and

F1 flange

TYPE: VODL/R1116/S10F1/G5.p4/ac CODE: 1555032200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075

psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S10F1/G5.p8/ac CODE: 1555032201

DESCRIPTION: pilot ratio 1:8, range 5-350 bar (72.5-5075 psi), std

setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S10F1/G5.p0/ac CODE: 1555032202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350

bar (725-5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

Relief compensated (R) configuration with SAE10 thread and

F2 flange

TYPE: VODL/R1116/S10F2/G5.p4/ac CODE: 1555032203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075

psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S10F2/G5.p8/ac CODE: 1555032204

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075

psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

TYPE: VODL/R1116/S10F2/G5.p0/ac CODE: 1555032205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350

bar (725-5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.



VODL/N1116/PB complete valves

Load sensitive (N) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VODL/N1116/38PB/G3.p4/ac CODE: 1555422101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/38PB/G5.p4/ac CODE: 1555422100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VODL/N1116/38PB/G5.p8/ac CODE: 1555422102

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VODL/N1116/38PB/G5.p0/ac CODE: 1555422103

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G1/2 thread

Pilot ratio 1:4

TYPE: VODL/N1116/12PB/G3.p4/ac CODE: 1555432101

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/N1116/2PB/G5.p4/ac CODE: 1555432100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VODL/N1116/12PB/G5.p8/ac CODE: 1555432102

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VODL/N1116/12PB/G5.p0/ac CODE: 1555432103

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.



Type VODL/V1116/CS Двусторонний тормозной клапан   counterbalance valves • Double acting • Vented



VODL/V1116/CS (38-12)

Nominal flow 60 l/min (15.9 US gpm)

Max. pressure 350 bar (5100 psi)

Oil leakage 0.25 cm3/min - 0.015 in3/min. (5 drops) at 210 bar - 3050 psi

Fluid mineral based oil

Viscosity from 10 to 200 cSt

Max. level of contamination 18/16/13 ISO4406

Fluid temperature with NBR seals from -20°C (-4°F) to 80°C (176°F)

Environmental temp. for working conditions from -40°C (-40°F) to 100°C (212°F)

Weight VODL/V1116/CS/38: 3.64 kg (8.02 lb) - VODL/V1116/CS/12: 3.50 kg (7.72 lb)



Complete valves

Vented (V) configuration with G3/8 thread

Pilot ratio 1:4

TYPE: VODL/V1116/CS/38/G3.p4.PR/ac CODE: 1554522102

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/38/G5.p4.PR/ac CODE: 1554522100

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VODL/V1116/CS/38/G5.p8.PR/ac CODE: 1554522105

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VODL/V1116/CS/38/G3.p0.PR/ac CODE: 1554522107

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/38/G5.p0.PR/ac CODE: 1554522101

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G3/8 thread and F2 flange

TYPE: VODL/V1116/CS/38F2/G5.p4.PR/ac CODE: 1556022100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 min (1.32 US gpm)

TYPE: VODL/V1116/CS/38F2/G5.p8.PR/ac CODE: 1556022101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/38F2/G5.p0.PR/ac CODE: 1556022102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



Complete valves

Vented (V) configuration with SAE8 thread

Pilot ratio 1:4

TYPE: VODL/V1116/CS/S8/G3.p4.PR/ac CODE: 1554522200

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/S8/G5.p4.PR/ac CODE: 1554522201

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VODL/V1116/CS/S8/G5.p8.PR/ac CODE: 1554522204

DESCRIPTION: Steel body, range 5-350 bar (72.5-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VODL/V1116/CS/S8/G3.p0.PR/ac CODE: 1554522206

DESCRIPTION: Steel body, range 5-210 bar (72.5-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/S8/G5.p0.PR/ac CODE: 1554522207

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with SAE8 thread and F2 flange

TYPE: VODL/V1116/CS/S8F2/G5.p4.PR/ac CODE: 1556022200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 min (1.32 US gpm)

TYPE: VODL/V1116/CS/S8F2/G5.p8.PR/ac CODE: 1556022201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/S8F2/G5.p0.PR/ac CODE: 1556022202



Complete valves

Vented (V) configuration with G1/2 thread

TYPE: VODL/V1116/CS/12/G5.p4.PR/ac CODE:1554532100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/12/G5.p8.PR/ac CODE: 1554532101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/12/G5.p0/ac CODE: 1554532102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G1/2 thread and F2 flange

TYPE: VODL/V1116/CS/12F2/G5.p4.PR/ac CODE: 1556032100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/12F2/G5.p8.PR/ac CODE: 1556032101

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/12F2/G5.p0.PR/ac CODE: 1556032102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.

Vented (V) configuration with SAE10 thread

TYPE: VODL/V1116/CS/S10/G5.p4.PR/ac CODE: 1554532200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/S10/G5.p8.PR/ac CODE: 1554532201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/S10/G5.p0/ac CODE: 1554532202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar



Complete valves

Vented (V) configuration with SAE10 thread and F2 flange

TYPE: VODL/V1116/CS/S10F2/G5.p4.PR/ac CODE: 1556032200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/S10F2/G5.p8.PR/ac CODE: 1556032201

DESCRIPTION: Steel body, pilot ratio 1:8, range 5-350 bar (72.5-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VODL/V1116/CS/S10F2/G5.p0.PR/ac CODE: 1556032202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.





Type VOSL/N1516 - VOSL/V1516 Односторонний тормозной клапан    Single acting • Load Sensitive (type N) • Vented (type V) • Configuration with F1 and F2 flange

VOSL/N1516 (12-34) - VOSL/V1516 (12-34)

Nominal flow 160 l/min (42.3 US gpm)

Max. pressure 350 bar(1) (5100 psi) - 400 bar(2) (5800 psi)

Oil leakage 0.5 cm3/min (0.030 in3/min) - 10 drops/min at 80% of pressure setting

Fluid mineral based oil

Viscosity from 10 to 200 cSt

Max. level of contamination 18/16/13 ISO4406

Fluid temperature with NBR seals from -20°C (-4°F) to 90°C (194°F)

Environmental temp. for working conditions from -20°C (-4°F) to 50°C (122°F)

Weight

VOSL/N1516/12: 2.50 kg (5.51 lb) - VOSL/N1516/34: 3.30 kg (7.27 lb)

VOSL/V1516/12: 2.50 kg (5.51 lb) - VOSL/V1516/34: 3.30 kg (7.27 lb)



VOSL/N1516 Complete valves

Load sensitive (N) configuration with G1/2 thread

Pilot ratio 1:4

TYPE: VOSL/N1516/12/G3.p4.PR/ac CODE: 1514632100

DESCRIPTION: Steel body, range 50-210 bar (725-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/12/G5.p4.PR/ac CODE: 1514632101

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/12/G7.p4.PR/ac CODE: 1514632102

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/N1516/12/G5.p8.PR/ac CODE: 1514632104

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/12/G7.p8.PR/ac CODE: 1514632105

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/N1516/12/G3.p0.PR/ac CODE: 1514632106

DESCRIPTION: Steel body, range 50-210 bar (725-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/12/G5.p0.PR/ac CODE: 1514632107

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/12/G7.p0.PR/ac CODE: 1514632108

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G1/2 thread and F1 flange

TYPE: VOSL/N1516/12F1/G5.p4.PR/ac CODE: 1515632100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/12F1/G5.p8.PR/ac CODE: 1515632101

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/12F1/G5.p0.PR/ac CODE: 1515632102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G1/2 thread and F2 flange

TYPE: VOSL/N1516/12F2/G5.p4.PR/ac CODE: 1515632103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/12F2/G5.p8.PR/ac CODE: 1515632104

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/12F2/G5.p0.PR/ac CODE: 1515632105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) 5 l/min (1.32 US gpm)



VOSL/N1516 Complete valves

Load sensitive (N) configuration with SAE10 thread

Pilot ratio 1:4

TYPE: VOSL/N1516/S10/G3.p4.PR/ac CODE: 1514632200

DESCRIPTION: Steel body, range 50-210 bar (725-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S10/G5.p4.PR/ac CODE: 1514632201

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S10/G7.p4.PR/ac CODE: 1514632202

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/N1516/S10/G5.p8.PR/ac CODE: 1514632204

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S10/G7.p8.PR/ac CODE: 1514632205

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/N1516/S10/G3.p0.PR/ac CODE: 1514632206

DESCRIPTION: Steel body, range 50-210 bar (725-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S10/G5.p0.PR/ac CODE: 1514632207

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S10/G7.p0.PR/ac CODE: 1514632208

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE10 thread and F1

flange

TYPE: VOSL/N1516/S10F1/G5.p4.PR/ac CODE: 1515632200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S10F1/G5.p8.PR/ac CODE: 1515632201

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S10F1/G5.p0.PR/ac CODE: 1515632202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE10 thread and F2

flange

TYPE: VOSL/N1516/S10F2/G5.p4.PR/ac CODE: 1515632203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S10F2/G5.p8.PR/ac CODE: 151563



VOSL/N1516 Complete valves

Load sensitive (N) configuration with G3/4 thread

TYPE: VOSL/N1516/34/G5.p4.PR/ac CODE: 1514642100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/34/G5.p8.PR/ac CODE: 1514642101

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/34/G5.p0.PR/ac CODE: 1514642102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G3/4 thread and F1 flange

TYPE: VOSL/N1516/34F1/G5.p4.PR/ac CODE: 1515642100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/34F1/G5.p8.PR/ac CODE: 1515642101

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/34F1/G5.p0.PR/ac CODE: 1515642102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with G3/4 thread and F2 flange

TYPE: VOSL/N1516/34F2/G5.p4.PR/ac CODE: 1515642103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/34F2/G5.p8.PR/ac CODE: 1515642104

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/34F2/G5.p0.PR/ac CODE: 1515642105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt





VOSL/N1516 Complete valves

Load sensitive (N) configuration with SAE12 thread

TYPE: VOSL/N1516/S12/G5.p4.PR/ac CODE: 1514642200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S12/G5.p8.PR/ac CODE: 1514642201

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S12/G5.p0.PR/ac CODE: 1514642202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE12 thread and F1

flange

TYPE: VOSL/N1516/S12F1/G5.p4.PR/ac CODE: 1515642200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S12F1/G5.p8.PR/ac CODE: 1515642201

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S12F1/G5.p0.PR/ac CODE: 1515642202

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Load sensitive (N) configuration with SAE12 thread and F2

flange

TYPE: VOSL/N1516/S12F2/G5.p4.PR/ac CODE: 1515642203

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S12F2/G5.p8.PR/ac CODE: 1515642204

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/N1516/S12F2/G5.p0.PR/ac CODE: 1515642205

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt



VOSL/V1516 Complete valves

Vented (V) configuration with G1/2 thread

Pilot ratio 1:4

TYPE: VOSL/V1516/12/G3.p4.PR/ac CODE: 1514732100

DESCRIPTION: Steel body, range 50-210 bar (725-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G5.p4.PR/ac CODE: 1514732101

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G7.p4.PR/ac CODE: 1514732102

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/V1516/12/G5.p8.PR/ac CODE: 1514732104

DESCRIPTION: Steel body, range 50-350 bar (72.5-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G7.p8.PR/ac CODE: 1514732105

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/V1516/12/G3.p0.PR/ac CODE: 1514732106

DESCRIPTION: Steel body, range 50-210 bar (725-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G5.p0.PR/ac CODE: 1514732107

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G7.p0.PR/ac CODE: 1514732108

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G1/2 thread and F1 flange

TYPE: VOSL/V1516/12F1/G5.p4.PR/ac CODE: 1515732100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12F1/G5.p8.PR/ac CODE: 1515732101

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12F1/G5.p0.PR/ac CODE: 1515732102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G1/2 thread and F2 flange

TYPE: VOSL/V1516/12F2/G5.p4.PR/ac CODE: 1515732103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12F2/G5.p8.PR/ac CODE: 1515732104

DESCRIPTION: Steel body, Pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12F2/G5.p0.PR/ac CODE: 1515732105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar





VOSL/V1516 Complete valves

Vented (V) configuration with G1/2 thread

Pilot ratio 1:4

TYPE: VOSL/V1516/12/G3.p4.PR/ac CODE: 1514732100

DESCRIPTION: Steel body, range 50-210 bar (725-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G5.p4.PR/ac CODE: 1514732101

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G7.p4.PR/ac CODE: 1514732102

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Pilot ratio 1:8

TYPE: VOSL/V1516/12/G5.p8.PR/ac CODE: 1514732104

DESCRIPTION: Steel body, range 50-350 bar (72.5-5075 psi), std

setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G7.p8.PR/ac CODE: 1514732105

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Zero differential pilot ratio

TYPE: VOSL/V1516/12/G3.p0.PR/ac CODE: 1514732106

DESCRIPTION: Steel body, range 50-210 bar (725-3050 psi), std setting

150 bar (2175 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G5.p0.PR/ac CODE: 1514732107

DESCRIPTION: Steel body, range 50-350 bar (725-5075 psi), std setting

280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12/G7.p0.PR/ac CODE: 1514732108

DESCRIPTION: Steel body, range 150-400 bar (2175-5800 psi), std

setting 350 bar (5075 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G1/2 thread and F1 flange

TYPE: VOSL/V1516/12F1/G5.p4.PR/ac CODE: 1515732100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12F1/G5.p8.PR/ac CODE: 1515732101

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12F1/G5.p0.PR/ac CODE: 1515732102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G1/2 thread and F2 flange

TYPE: VOSL/V1516/12F2/G5.p4.PR/ac CODE: 1515732103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12F2/G5.p8.PR/ac CODE: 1515732104

DESCRIPTION: Steel body, Pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/12F2/G5.p0.PR/ac CODE: 1515732105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)



VOSL/V1516 Complete valves

Vented (V) configuration with G2/4 thread

TYPE: VOSL/V1516/34/G5.p4.PR/ac CODE: 1514742100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/34/G5.p8.PR/ac CODE: 1514742101

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/34/G5.p0.PR/ac CODE: 1514742102

DESCRIPTION: Steel body, zero differential pilot ratio, sange 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G3/4 thread and F1 flange

TYPE: VOSL/V1516/34F1/G5.p4.PR/ac CODE: 1515742100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/34F1/G5.p8.PR/ac CODE: 1515742101

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/34F1/G5.p0.PR/ac CODE: 1515742102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with G3/4 thread and F2 flange

TYPE: VOSL/V1516/34F2/G5.p4.PR/ac CODE: 1515742103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/34F2/G5.p8.PR/ac CODE: 1515742104

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/34F2/G5.p0.PR/ac CODE: 1515742105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

For other configurations please contact our Sales Dpt.





VOSL/V1516 Complete valves

Vented (V) configuration with SAE12 thread

TYPE: VOSL/V1516/S12/G5.p4.PR/ac CODE: 1514742200

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/S12/G5.p8.PR/ac CODE: 1514742201

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/S12/G5.p0.PR/ac CODE: 1514742202

DESCRIPTION: Steel body, zero differential pilot ratio, sange 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with SAE12 thread and F1 flange

TYPE: VOSL/V1516/S12F1/G5.p4.PR/ac CODE: 1515742100

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/S12F1/G5.p8.PR/ac CODE: 1515742101

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/S12F1/G5.p0.PR/ac CODE: 1515742102

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

Vented (V) configuration with SAE12 thread and F2 flange

TYPE: VOSL/V1516/S12F2/G5.p4.PR/ac CODE: 1515742103

DESCRIPTION: Steel body, pilot ratio 1:4, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/S12F2/G5.p8.PR/ac CODE: 1515742104

DESCRIPTION: Steel body, pilot ratio 1:8, range 50-350 bar (725-5075 psi),

std setting 280 bar (4060 psi) @ 5 l/min (1.32 US gpm)

TYPE: VOSL/V1516/S12F2/G5.p0.PR/ac CODE: 1515742105

DESCRIPTION: Steel body, zero differential pilot ratio, range 50-350 bar

(725-5075 psi), std setting 280 bar (4060 psi) @ 5 l/min





Type VODL/N1516/CS - VODL/V1516/CS Двусторонний тормозной клапан    counterbalance valves • Double acting • Load Sensitive (type N) • Vented (type V)



VODL/N1516/CS (12-34) - VODL/V1516/CS (12-34)

Nominal flow 160 l/min (42.3 US gpm)

Max. pressure 350 bar(1) (5100 psi) - 400 bar(2) (5800 psi)

Oil leakage 0.5 cm3/min (0.030 in3/min) - 10 drops/min at 80% of pressure setting

Fluid mineral based oil

Viscosity from 10 to 200 cSt

Max. level of contamination 18/16/13 ISO4406

Fluid temperature with NBR seals from -20°C (-4°F) to 90°C (194°F)

Environmental temp. for working conditions from -20°C (-4°F) to 50°C (122°F)

Weight

VODL/N1516/CS/12: 5.40 kg (11.90 lb) - VODL/N1516/CS/34: 5.30 kg (11.68 lb)

VODL/V1516/CS/12: 5.40 kg (11.90 lb) - VODL/V1516/CS/34: 5.30 kg (11.68 lb)



VODL/N1516 Complete valves

Load sensitive (N) configuration with G1/2 thread

Pilot ratio 1:4

TYPE: VODL/N1516/CS/12/G3.p4.PR/ac CODE: 1556532100

DESCRIPTION: Steel body, range 50-210 bar (725-3050 psi), std setting
